Device Overview
Anker SOLIX X1 is a modular home energy storage system for solar self-consumption, backup power, and time-of-use energy shifting. It is best treated on EnergyMeterHub as a battery-storage system rather than as a standalone energy meter, EV charger, gateway, or generic solar inverter page.
Core Battery Fit
The X1 platform scales by combining power modules and battery modules. Anker's official US product page presents a 5 kWh to 180 kWh capacity range and a 3 kW to 36 kW power range for the broader X1 platform, while the AC-coupled US specification sheet lists X1-P6K-B10-US, X1-P6K-B15-US, and X1-P6K-B20-US configurations and two-stack variants.
Installation And Backup Context
The reviewed AC-coupled specification sheet lists wall or ground installation options, NEMA 4 enclosure rating, 120/240 V split-phase off-grid output, backup controller connectivity, and transfer switching under 20 ms. Backup performance depends on the selected X1 configuration, backup controller, installation design, and local code requirements.
Data And Cloud Context
The X1 system uses Anker SOLIX app and connectivity through the backup-controller path. The reviewed official specification sheet lists WLAN, Bluetooth, Ethernet, and optional 4G connectivity via the backup controller. Treat cloud/app access as important for user monitoring and management rather than as an energy-meter local API claim.
Selection Notes
Use the stored scalar fields as comparison helpers only. The X1 family is modular, so buyers should confirm the exact X1-P6K-B10-US, X1-P6K-B15-US, X1-P6K-B20-US, or multi-stack configuration with an installer before comparing capacity, backup output, or final price.
